Valves

Products in Valves category

Ball Valves

ball valve

Ball Valve Seats

Fluorotech manufactures ball valve soft seats of PTFE, RPTFE, modified PTFE (TFM), PCTFE, PFA and PVDF.
We also manufacture seats from high performance thermoplastics including PEEK, PPS along with some specially developed grades of Polyamides and PEEK+PTFE blends, Devlon & UHMWPE.

TMBV-Ball-valve

TMBV Seats

Fluorotech manufactures Trunnion Mounted Ball Valves seats from 2 “to 24″ in various materials. Seats complete with or without O-rings, back up, graphite, soft seats are manufactured in accordance with the general principles of standardization and adaptation to the needs of customers. The material offered by Fluorotech are: A 105 , LF2 , SS 304 /316 , Duplex grades F51 & F55 , Monel , Inconel etc. with the soft seats in PEEK, PTFE, RPTFE, CFT, Devlon, Nylon etc.

PCTFE

Cryogenic Application Seats

Very broad temperature range of application which includes extremely low temperatures : from – 196°C to + 150°C in continuous use and up to + 200°C as peak temperature,
• high mechanical Strength and in particulate very low creep under compression,
• non-flammable, even in presence of high oxygen concentration
• very high chemical inertness towards all inorganic chemicals and towards most organic chemicals,
• excellent resistance to ultra-violet and X-ray radiation,
• very good impermeability to liquids and gases even at low temperatures

Butterfly Valves

PEEK

High Pressure Application Seals

This new age polymer specially developed for hi-performance butterfly valves can withstand the temperature of around 260 Deg C. These seats can be used for fire safe application as well.

Butterfly-valve-2

Butterfly Valve Liners

Fluorotech Engg has developed unique process for Butterfly valve liners by isostatic molding . Fluorotech manufactures a wide range of components for butterfly valves, including liners (seats), backup as well as other molded and machined components in a variety of materials. We are also specializes in PTFE/PFA lined disc and supply as a set with the liners.All products are custom manufactured to individual customer specifications.

PFA-Lined_Disc

PFA Lined, Stem and Disc

Fluorotech is specialized in PFA lined butterfly liner and disc.

Plug Valve

Plug-valve-Sleeves

Plug Valve Sleeves

Fluorotech manufacturers PTFE/CFT/TFM1600 plug valve sleeves by Isostatic moulding. We are specialized in manufacturing of PFA lined plug valve sleeve. Sizes developed upto 42 inch.

PFA Lining

PFA LINED SLEEVE
PFA-Lined-Valve-Body

PFA Lined Valve Body

Fluorotech is specialized in manufacturing PFA lined Body, Plugs and Sleeves.

Materials used can be Stainless Steel, Carbon Steel and other special Alloys in accordance with ASTM, DIN, ANSI Standards.

GATE SEAL

Gate Valve Seals

We have developed high pressure gate valve seats with soft inserts as well as stellite coating

Valve-Diaphragms

Diaphragms

Fluorotech is specialized in manufacturing PTFE,PFA and TFM1600 Diaphragms.
